Home > Product > Sandwich Wall Panel > PU Edge Rock Wool Sandwich Wall Panel
|
Product Name: |
PU Foaming Rock Mineral Wool Sandwich Wall Panel |
|
Material: |
High density Rock wool |
|
Panel Thickness: |
40-200 mm |
|
Steel Thickness: |
0.4-0.8 mm |
|
Fire Rating: |
A |
1. Industrial Buildings
Roofs and walls of factories/warehouses, offering insulation, fireproofing, and structural strength.
2. Commercial Buildings
Enclosures for malls, exhibition halls, and stadiums, meeting energy efficiency and safety standards.
3. Cold Storage & Logistics
Ideal for cold storage facilities and refrigerated transport due to superior thermal insulation.
4. Residential & Temporary Structures
Modular/prefab housing with fire safety and thermal comfort.
| PU Edge Rock Wool Sandwich Wall Panel | |
| Surface Steel Thickness | 0.4 mm— 0.8mm |
| Surface Panel Material | PPGI /Stainless steel/Aluminium sheet |
| Panel Thickness | 50mm/60mm/75mm/80mm/100mm/150mm/200mm |
| Panel Standard Width | 500mm-1000mm |
| Panel Length | Customized according to customer requirements |
| Core Material Density | 80-140kg/m³ |
| Combustion Performance | Class A |
| Thermal Insulation Property | ≤0.04W（M.K） |
| Noise Reduction Performance | Average sound insulation ≥37dB (50mm) |
| Durability | Chemically stable, surpassing organic materials |
| Operating Temperature | -268°C to 700°C |
| Inner/outer steel plate thickness, coating, and manufacturer can be customized per client requirements | |
The factory covers an area of over 50 acres and is located in the Southern Economic Development Zone of Renqiu City, Cangzhou, Hebei Province.
