Product Name: |
Polyurethane Cold Room Panel |
|
Sheet thickness |
0.4 mm— 0.8mm |
|
Surface Panel Material |
PPGI /Stainless steel /Aluminium sheet |
|
Panel Thickness |
50mm/75mm /100mm /150mm /200mm |
|
Panel Width |
1120mm or customized |
Polyurethane cold storage panels are high-performance insulation boards used in refrigerated warehouses and food processing units. Made from polyurethane foam (PIR) sandwiched between metal or plastic sheets, these panels provide excellent thermal resistance, durability, and moisture protection.
Key features:
Strong Insulation: Low thermal conductivity keeps temperatures stable, saving energy.
Lightweight & Durable: Easy to install yet resistant to wear, corrosion, and pests.
Fire-Resistant: Some panels include flame-retardant additives for safety.
Customization: Available in various thicknesses (50mm–200mm), colors, and surface finishes.
Eco-Friendly: CFC-free foam reduces environmental impact.
Applications: Used in cold rooms, freezer warehouses, pharmaceutical storage, and industrial buildings. The panels tight joints prevent air leaks, ensuring efficient cooling.
| Polyurethane Cold Room Panel | |
| Surface Steel Thickness | 0.4 mm— 0.8mm |
| Surface Panel Material | PPGI /Stainless steel/Aluminium sheet |
| Panel Thickness | 50mm/75mm/100mm/150mm/200mm |
| Panel Width | 1120mm or customized |
| Panel Length | Customized according to customer requirements |
| Core Material Density | 40±2 kgs/m³ |
| Usual Colors | White gray, Silver gray, Ocean blue, Scarlet red, etc. (Refer to actual product) |
| Thermal Conductivity | ≤0.025 (W/m·K) |
| Installation Method | Horizontal and Vertical |
| Compressive Strength | 2.0 — 2.7 (kg/cm²) |
| Recommended Coating | 150g/m² Hot dip galvanizing coating |
| Rocommended Steel Manufacturers | Baosteel, Ye Chien, Bluescope, Guanzhou, Xinyu, Shenlong and so on |
| Project | Temperature |
Panel thic kness |
| Processing room | 10°C | 50 mm |
| Fruit, vegetable, dry food | 0°C~-5°C | 50 mm |
| Medicine, cake, pastry,chemical material | 0°C~-5°C | 75 mm |
| lce storage room | -5°C~-10°C | 75 mm |
| Fish, meat storage | -18°C~-25°C | 150 mm |
| Deep freezer | -25°C~-35°C | 200 mm |
